| IPC264EA-AHDZK-I1 | IPC264EA-AHDX4K-I1 |
Camera |
Sensor | 1/1.8" CMOS |
Min. Illumination | Color: 0.0003 Lux (F1.2, AGC ON), BW: 0.0001 Lux (F1.2, AGC ON), 0 Lux with IR | Color: 0.0005 Lux (F1.6, AGC ON), BW: 0.0003 Lux (F1.6, AGC ON),0 Lux with IR |
Day/Night | IR-cut filter with auto switch (ICR) |
Shutter | Auto/Manual, 1 to 1/100000 s |
WDR | 140 dB |
S/N | >56 dB |
Lens |
Focal Length | 2.8 to 12 mm | 8 to 32 mm |
Optical Zoom | 4X |
Iris | F1.2 | F1.6 |
Field of View (H) | 106.6° to 51.3° | 42.6° to 15.2° |
Field of View (V) | 56.9° to 28.6° | 23.5° to 8.9° |
Field of View (D) | 131.1° to 63.1° | 52.4° to 17.9° |
Iris Type | P-iris |
DORI |
DORI Distance (Detect) | 68.0 m to 166.2 m (223.0 ft. to 545.2 ft.) | 124.1 m to 496.6 m (407.3 ft. to 1629.1 ft.) |
DORI Distance (Observe) | 27.2 m to 66.5 m (89.2 ft. to 218.1 ft.) | 49.7 m to 198.6 m (163.1 ft. to 651.6 ft.) |
DORI Distance (Recognize) | 13.6 m to 33.2 m (44.6 ft. to 109.0 ft.) | 24.8 m to 99.3 m (81.4 ft. to 325.8 ft.) |
DORI Distance (Identify) | 6.8 m to 16.6 m (22.3 ft. to 54.5 ft.) | 12.4 m to 49.7 m (40.7 ft. to 162.9 ft.) |
Illuminator |
Illumination Distance (IR) | 100 m (328.1 ft) |
Wavelength | 850 nm |
IR On/Off Control | Auto/Manual |
Video |
Frame Rate-Main Stream | 4 MP (2688 × 1520), max. 60 fps |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
Frame Rate-Sub Stream | 1080P (1920 × 1080), max. 60 fps |
Video Bit Rate | 128 Kbps to 16 Mbps |
Privacy Mask | Up to 8 areas (8 blacks / 8 mosaics) |
ROI | Support |
Video Stream | Triple streams |
OSD | Up to 10 OSDs |
Frame Rate-Third Stream | D1 (720 × 576), max. 60 fps |
Frame Rate Recommendation | 2688 × 1520@60 fps + 1080P@60 fps + D1@60 fps |
Image |
White Balance | Auto&Outdoor&Fine Tune&Sodium Lamp&Locked&Auto2 |
Digital Noise Reduction | 2D/3D DNR |
Smart IR | Support |
Flip | Normal&Flip Vertical&Flip Horizontal&180°&90°Clockwise&90°Anti-clockwise |
HLC | Support |
Defog | Digital defog |
Intelligent |
Metadata Analyse | Support human body, motor vehicle and non-motor vehicle image capture and attribute collection |
Recognition | |
People Counting | Support people flow counting and crowd density monitoring |
Exception Detection | Object removed, Object Left Behind, Scene change, Defocus detection | Object removed, Object Left Behind |
Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
Events |
Basic Detection | Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind, Scene change, Defocus detection | Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind |
General Function | Watermark&IP Address Filtering&Access Policy&ARP Protection&RTSP Authentication&User Authentication&HTTP authentication&Alarm input&Alarm output |
Audio |
Audio Compression | G.711U&G.711A |
Audio Bitrate | 128 Kbps |
Sampling Rate | 16KHZ |
Storage |
Edge Storage | MicroSD, up to 512 GB |
Network Storage | ANR&NAS(NFS) |
Network |
Protocols | IGMP, RTP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, SSH, TLS1.3 |
Compatible Integration | API, SDK, ONVIF (Profile S, Profile G, Profile T, Profile M) |
User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
Security | Password protection&Strong password&HTTPS encryption&Export operation logs&Basic and digest authentication for RTSP&Digest authentication for HTTP&TLS 1.2&WSSE and digest authentication for ONVIF |
Client | EZStation, UNV-Link, UNV-Link Pro |
Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above&Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
Interface |
Audio I/O | 2 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] |
Alarm I/O | 3/2 |
Serial Port | 1 × RS485 |
Built-in Mic | Support, built-in mic*2 |
Built-in Speaker | Support |
Network | 1 × RJ45 10 M/100 M/1000 M Base-TX Ethernet |
Certification |
EMC | CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
Safety | CE LVD (EN 62368-1:2014+A11:2017) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Protection | IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) |
General |
Power | DC 12 V (±25%), PoE+ (IEEE 802.3at) |
Power Consumption | 16 W | 19 W |
Power Interface | Ø5.5 mm coaxial power plug |
Dimensions | 406 mm × 126 mm × 130 mm (16.0" × 5.0" × 5.1") (L × W × H) |
Weight | 1.92 kg (4.23 lb.) | 1.86 kg (4.10 lb.) |
Working Environment | -40 ℃ to 60 ℃ (-40 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing) |
Surge Protection | 6 KV |
Reset Button | Support |
Heater | Support |
