PKC2641-Z100-P-NB
4MP Overseas Recognition Of Vehicle License Plate Bullet IP Camera
• 1/1.8" progressive scan CMOS.
• Up to 2688 × 1520 resolution with real-time video.
• Supports Wise-ISP for enhanced image quality.
• Automatic gain control, white balance, and WDR for various light conditions.
• Video frame rate upgraded to 60 fps.
• Built-in vehicle and license plate recognition algorithm can recognize standard license plates of multiple countries.
• Supports plate allowlist and blocklist configuration.
• Supports Micro SD cards of up to 512GB.
• IP67 and IK10 protection.
Specification
Download
How to buy
 PKC2641-Z100-P-NBPKC2641-Z100-IR-P-NBPKC2641-Z28-P-NBPKC2641-Z28-IR-P-NBPKC2641-Z80-P-NBPKC2641-Z80-IR-P-NB
Camera
Sensor1/1.8-inch 4MP CMOS
Focal length10 to 50mm10 to 50mm2.8 to 12mm2.8 to 12mm8 to 32mm8 to 32mm
ShutterAuto, range: 1/500 to 1/100000sAuto, range: 1/500 to 1/100000sAuto, range: 1/500 to 1/100000sAuto, range: 1/500 to 1/100000sAuto, range: 1/200 to 1/100000sAuto, range: 1/200 to 1/100000s
Minimum illumination0.002lux (F1.7)0.002lux (F1.7)0.002lux (F1.7)0.002lux (F1.7)0.0005lux (F1.4)0.0005lux (F1.4)
FOVHorizontal FOV: 34.3° to 8.7°,
Vertical FOV: 19.9° to 4.8°,
Diagonal FOV: 40.5° to 9.8°		Horizontal FOV: 34.3° to 8.7°,
Vertical FOV: 19.9° to 4.8°,
Diagonal FOV: 40.5° to 9.8°		Horizontal FOV: 106.4° to 50.3°,
Vertical FOV: 57.1° to 27.8°,
Diagonal FOV: 127.4° to 57.3°		Horizontal FOV: 106.4° to 50.3°,
Vertical FOV: 57.1° to 27.8°,
Diagonal FOV: 127.4° to 57.3°		Horizontal FOV: 42° to 15.5°,
Vertical FOV: 23.1° to 8.8°,
Diagonal FOV: 48.5° to 18.3°		Horizontal FOV: 42° to 15.5°,
Vertical FOV: 23.1° to 8.8°,
Diagonal FOV: 48.5° to 18.3°
WDR120 dB
S/N> 50 dB
Image collection format2688*1520@60,2688*1520@50,2688*1520@30 (default),2688*1520@25
ResolutionMain stream: 2688*1520, 1080P (default), 720P, D1; Sub stream: 720P (default), D1, 2CIF, CIF; Third stream: D1 (default), 2CIF, CIF
Frame rate60, 50, 30 (default), 25, 22, 20, 18, 16, 15, 12.5, 10, 8, 6, 5, 4, 3, 2, 1
Video compressionH.264 (default), H.265
ROISupports up to 8 regions
HLCSupport
BLCSupport
DefogDigital defog
Digital Noise Reduction3D DNR
Video OSDSupports 8 overlay areas and allows contents including date, time, date&time, zoom ratio, custom contents
Image OSDSupports 8 overlay areas and allows contents including time, license plate number, device ID, camera ID, allowlist, image authentication ID, custom contents (3 items), location
Smart
Application scenario≤ 80km/h for regular roads;
Camera with the focal length of 10 to 50mm can be used for regular roads		≤ 80km/h for regular roads;
Camera with the focal length of 10 to 50mm can be used for regular roads		≤ 30km/h for entrances and exits, ≤ 80km/h for regular roads;
Supports simultaneous application to road and entry/exit scenes without switching		≤ 30km/h for entrances and exits, ≤ 80km/h for regular roads;
Supports simultaneous application to road and entry/exit scenes without switching		≤ 80km/h for regular roads;
Camera with the focal length of 8 to 32mm can be used for regular roads		≤ 80km/h for regular roads;
Camera with the focal length of 8 to 32mm can be used for regular roads
Vehicle detection modeSupports video detection
License plate number recognitionSupports recognition of license plates with numbers and letters by default
List configurationSupports allowlist and blocklist configuration, each list allows 20,000 items
Supports import, export, add, and delete operations
Barrier opening policyOpen barrier only for the recognized vehicles
Open barrier for all vehicles
Open barrier only for vehicles on the allowlist
Open barrier for vehicles not on the blocklist
Configurable Boolean output ID
Storage
Edge storageSupports ANR with a Micro SD card, up to 512GB
Structure
IlluminationBuilt-in integrated illumination module, including 5 warm light LEDs, 50m illumination distance, automatic on/off controlBuilt-in integrated illumination module, including 5 warm light LEDs, 50m illumination distance, automatic on/off controlBuilt-in integrated illumination module, including 4 warm light LEDs, 50m illumination distance, automatic on/off controlBuilt-in integrated illumination module, including4 IR LEDs, 50m illumination distance, automatic on/off controlBuilt-in integrated illumination module, including 5 IR LEDs, 50m illumination distance, automatic on/off controlBuilt-in integrated illumination module, including 5 IR LEDs, 50m illumination distance, automatic on/off control
Bracket3-axis mounting bracket
Junction boxThe camera comes with a junction box for storing tail cable
Network
ProtocolsIGMP,IPv6,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTSP,DNS,DDNS,NTP,UPnP,HTTP,HTTPS,802.1x,SNMP,QoS,SSL/TLS,SSH,IPv4
Compatible IntegrationONVIF (Profile S, Profile G, Profile T),SDK,
API
Interface
Network interface1×10M/100M RJ45
Serial port2 × RS485
Boolean output2 relay outputs, withstand voltage: AC 125V/0.3A, DC 30V/1A2 relay outputs, withstand voltage: AC 125V/0.3A, DC 30V/1A2 relay outputs, withstand voltage: AC 125V/0.3A, DC 30V/1A2 relay outputs, withstand voltage: AC 125V/0.3A, DC 30V/1A2 relay output, withstand voltage: AC 125V/0.3A, DC 30V/1A2 relay output, withstand voltage: AC 125V/0.3A, DC 30V/1A
Boolean input2 x input, supports level (up to DC 5V) and switch signal
Audio interface1 × audio input, 1 × audio output
Storage interface1 × Micro SD card slot
Reset buttonSupport
Hardware Specification
Wiegand InterfaceSupports Wiegand output
General
Power supplyDC12V + 25% - 25%
Max. power consumption: 20W
Supports PoE (802.3at, class 4)
Dimensions (L×W×H)406mm x 126mm x 130mm
Weight2.02kg2.02kg1.87kg1.87kg1.91kg1.91kg
Operating environment-40℃ to 60℃, ≤90% RH
Ingress protectionIP67, IK10
HeaterN/A
Compliance
NDAA CompliantSupport
