LAMP-IS16@A-F-OS | ||||||||
Structure | ||||||||
Tail cable | 1 x power input, 1 x strobe trigger input | |||||||
Power | 30W | |||||||
Be in common use | ||||||||
Weight | 1.5 kg | |||||||
Ingress protection | IP66 | |||||||
Bracket rotation angle | -90° to 90° | |||||||
Dimensions (L × W × H) | 1159×230×61mm | |||||||
Power supply | 200-240Vac 50/60Hz | |||||||
LED strobe | ||||||||
Trigger mode | Level trigger, switch trigger | |||||||
Trigger frequency | 100Hz | |||||||
Beam angle | 0-40% | |||||||
Light type | Infrared strobe light |
