LAMP-IH25@M3-F-OS | ||||||||
LED strobe | ||||||||
Power consumption | Default power is 4.4W(≤ 40W) | |||||||
Light type | Infrared flash & white flash & infrared strobe | |||||||
Luminous angle | 10° | |||||||
Trigger frequency | 100Hz | |||||||
Optimal fill light distance | 15~30m | |||||||
Trigger mode | Level trigger, switch trigger | |||||||
Beam angle | 0-40% | |||||||
LED lamp bead wavelength | 850nm | |||||||
White light flash | ||||||||
White light flash lifetime | More than 10 million times | |||||||
Output energy | ≤100J | |||||||
Flash brightness | 8-level adjustable | |||||||
Color temperature | ≤7000K | |||||||
Return time | ≤50ms | |||||||
Duration of flash | 1/10000s~1/1000s | |||||||
White light flash trigger mode | Level trigger | |||||||
Gas explosion level | 1~8 level adjustable | |||||||
Fill light distance | 15~30 m | |||||||
Red and White Switch | Switch by frequency | |||||||
Filter form | Window shades | |||||||
Be in common use | ||||||||
Dimensions (L × W × H) | 452*279*279mm | |||||||
Weight | 6.8kg | |||||||
Ingress protection | IP65 | |||||||
Bracket rotation angle | -45° to 45° | |||||||
Power supply | 200-240Vac 50/60Hz | |||||||
Length of tail line | 4.5m | |||||||
Communication interface | RS485 | |||||||
Operating environment | -40℃~70℃,10~95%RH |
