RD106@A-1-OS | ||||||||
Performance | ||||||||
Number of lanes | 1 | |||||||
Vehicle capture rate | ≥99% | |||||||
Speed measurement error | ≥100km/h (-1-0)km/h <100km/h(-0.5-0)km/h | |||||||
Trigger Consistency | ≤±0.5m | |||||||
Speed measurement range | 10 km/h ~250km/h | |||||||
Tracking distance | 18~38m | |||||||
Mounting height | 4~8m | |||||||
Lane width | 2.75~5m adjustable | |||||||
Interface Characteristics | ||||||||
Power supply | RS485 | |||||||
Communication interface | DC9~12V 0.3A | |||||||
General Features | ||||||||
Weight | 0.45kg | |||||||
Antenna beam 3dB width | 6°×6° | |||||||
Working center frequency | 24.15GHz±45MHz | |||||||
Power waste | ≤2W | |||||||
Operation temperature | -40℃~70℃ | |||||||
Working humidity | 0-95%RH | |||||||
Protection grade | IP66 | |||||||
Dimensions (L × W × H) | 205X221X191mm |
