IVT2600@A-A16S-OS
16-CH Traffic Recording Terminal Server
• Embedded Linux OS, 24/7 stable operation, better protection against hacker and virus attacks.
• Dual NICs allow two physical networks.
• 20 * Gigabit Ethernet interfaces (RJ45) and 2 * Gigabit optical interfaces.
• Supports CIF, D1, 720P, 1080P, 2K, and 4K video input.
• Powerful video processing functions, supports decoding mainstream video compression formats including H.265 and H.264.
• Supports text OSD, including plate numbers, time, location, etc.
• Supports composition of multiple images.
• Supports direct iSCSI block storage, instant video retrieval and playback.
• Supports image storage, search, view, export, and upload.
• Supports data acquisition through serial port.
• Supports S.M.A.R.T.
• Supplied with 1*4TB hard disk.
• Die-cast aluminum chassis with elegant appearance, effective shields electromagnetic interferences to ensure stable and reliable operation.
How to buy
 IVT2600@A-A16S-OS
Device Specifications
Video decodingH.264, H.265
Camera connectionMax 16 channels
Image compositionSupports composition of 2, 3, 4, or 6 images
Image operationsImage storage, search, view, export, and uploads
Image OSDText OSD including plate number, time, location, etc., on single or composite images
Hard disk storageSupplied with 1*4TB hard disk
Expansion to 4 * 3.5” SATA disk, up to 8TB each
External interfaces
Network interfaceDual NICs with support for dual-network isolation dual-network interconnection.
NIC1: 16 * Gigabit Ethernet interfaces (RJ45).
NIC2: 2 * Gigabit optical interface, 4 * Gigabit Ethernet interfaces (RJ45).
USB interface2 * USB 3.0, compatible with USB 2.0
Serial interface2 x RS-232, 2 x RS-485
Alarm input2 x alarm input (phoenix connector)
Alarm output2 x alarm output (phoenix connector)
Power outputDC12V, 500mA
Power inputDC12V, 10A
Hardware Parameter
Power consumption< 30W (with 1 HDD, and heating module off)
< 85W (with 1 HDD, and heating module on)
< 110W (with HDD fully configured, and heating module on)
Operating temperature-30ºC to 70ºC
Operating humidity5% to 95% (noncondensing)
WeightWith 1 supplied HDD: < 7kg
Fully loaded with HDD: < 9kg
Dimensions350mm(W) × 320mm(D) × 72mm(H)
Certification
EMCCE EMC:
EN 55032: 2015+A11:2020+A1:2020
EN 55035: 2017+A11:2020
EN 61000-3-3: 2013+ A1:2019+A2:2021
EN IEC 61000-3-2: 2019+A1:2021
SafetyCE LVD:EN IEC 62368-1:2020+A11:2020
