Channel | Channel 1 (Panorama) | Channel 2 (Detail) |
Camera | ||
Sensor | 1/2.8" CMOS | |
Min. Illumination | Color: 0.002 lux (F1.6, AGC ON) 0 lux with IR | Color: 0.002 lux (F1.6, AGC ON) 0 lux with IR/Warm light |
Day/Night | IR‑cut filter with auto switch (ICR) | |
Shutter | Auto/Manual, 1 to 1/100000 s | |
WDR | 120 dB | |
S/N | >52 dB | |
Lens | ||
Focal Length | 2.8 mm | 2.8 to 12 mm |
Optical Zoom | N/A | 4X |
Iris | F1.6 | |
Field of View (H) | 102.4° | 106.6° ~ 30.6° |
Field of View (V) | 54.9° | 56.5° ~ 17.4° |
Field of View (D) | 133.1° | 138.6° ~ 37.6° |
DORI | ||
DORI Distance (Detect) | 43.4 m (142.5 ft) | 43.4 m ~ 162.9 m (142.5 ft ~ 534.6 ft) |
DORI Distance (Observe) | 17.4 m (57.0 ft) | 17.4 m ~ 65.2 m (57.0 ft ~ 213.8 ft) |
DORI Distance (Recognize) | 8.7 m (28.5 ft) | 8.7 m ~ 32.6 m (28.5 ft ~ 106.9 ft) |
DORI Distance (Identify) | 4.3 m (14.3 ft) | 4.3 m ~ 16.3 m (14.3 ft ~ 53.5 ft) |
Illuminator | ||
Wavelength | 850 nm | |
Light On/Off Control | Auto/Manual | |
Illumination Distance (IR) | 10 m (32.8 ft) | 50 m (164.0 ft) |
Illumination Distance (Warm Light) | N/A | 10 m (32.8 ft) |
Image | ||
Defog | Digital Defog | |
White Balance | Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2 | |
Digital Noise Reduction | 2D/3D DNR | |
Smart IR | Support | |
Flip | Normal, Flip Vertical, Flip Horizontal, 180° | |
HLC | Support | |
BLC | Support | |
Intelligent | ||
Linkage Function | Support. Triggered by fixed lens via smart intrusion prevention function to track target | |
Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non‑motor vehicle and vehicle) | |
Video | ||
Frame Rate‑Main Stream | 2MP (1920 x 1080) @25 fps (Default) 2MP (1920 x 1080), Max 25 fps 720P (1280 x 720), Max 25 fps | |
Frame Rate‑Sub Stream | 720P (1280 x 720), Max 25 fps D1 (720 x 576), Max 25 fps 640 x 360, Max 25 fps 2CIF (704 x 288), Max 25 fps CIF (325 x 288), Max 25 fps | |
Privacy Mask | 24 areas, up to 4 areas per scene | |
Video Compression | Ultra 265, H.265, H.264, MJPEG | |
Video Bit Rate | 128 Kbps to 16 Mbps | |
U‑code | Support (Main stream) | |
ROI | Support | |
Video Stream | Dual Streams | |
OSD | Up to 4 OSDs | |
Events | ||
Basic Detection | Motion Detection, Audio Detection | |
General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication | |
PTZ | ||
Pan Range | N/A | 0° ~ 345° |
Pan Speed | N/A | 1°/s ~ 40°/s |
Tilt Range | 18° ± 5° | ‑10° ~ 100° |
Tilt Speed | N/A | 2°/s ~ 50°/s |
Number of Presets | N/A | 256 |
Preset Patrol | N/A | 16 patrols, up to 64 presets for each patrol |
Patrol Stay Time | 1000 s to 1800 s | |
Home Position | N/A | Support |
Audio | ||
Audio Compression | G.711U, G.711A | |
Audio Bitrate | 128 Kbps | |
Two‑way Audio | Support | |
Suppression | Support | |
Sampling Rate | 16KHz | |
Storage | ||
Edge Storage | Micro SD, up to 512 GB | |
Network Storage | ANR, NAS (NFS) | |
Network | ||
Protocols | SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS | |
Compatible Integration | ONVIF (Profile S, Profile G, Profile M), API, SDK | |
User/Host | Up to 32 users. 3 user levels: administrator, common user and operator | |
Security | TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF | |
Client | EZStation, UNV‑Link, UNV‑Link Pro | |
Web Browser | Plug‑in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ | |
Interface | ||
Built‑in Mic | Built‑in two mics | |
Built‑in Speaker | Support | |
Network | 1 × RJ45 10 M/100 M Base‑TX Ethernet | |
Certification | ||
EMC | CE‑EMC (EN55032:2015; EN55024:2010+A1:2015; EN61000‑3‑2:2014; EN61000‑3‑3:2013) FCC (FCC CFR 47 part15 B, ANSI C63.4‑2014) | |
Safety | CE LVD (EN 62368‑1:2014+A11:2017; EN 62368‑1:2014) UL (UL 62368‑1, 2nd Ed., Issue Date: 2014‑12‑01) | |
Environment | CE‑ROHS (2011/65/EU) | |
Protection | IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) | |
General | ||
Power | DC12V, PoE+ (IEEE 802.3at) | |
Power Consumption | MAX 16W | |
Power Interface | Ø5.5 mm coaxial power plug | |
Dimensions | Wall Mount: 192 x 134 x 302 mm (7.6" x 5.3" x 11.9") (L x W x H) Ceiling Mount: 154 x 134 x 363 mm (6.1" x 5.3" x 14.3") (L x W x H) | |
Weight | 1.03 kg (2.27 lb) | |
Working Environment | ‑20 ℃ to 60 ℃ (‑4 ℉ to 140 ℉), Humidity: ≤ 95% RH (non‑condensing) | |
Storage Environment | ‑30 ℃ to 70 ℃ (‑22 ℉ to 158 ℉), Humidity: ≤ 95% RH (non‑condensing) | |
Surge Protection | 2 KV | |
Reset Button | Support | |
Web Client Language | 22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak |
