Channel | Channel 1 | Channel 2 |
Camera | ||
Max Resolution | 4 MP | |
Sensor | 1/3.0" CMOS | |
Min. Illumination | Colour: 0.002 lux (F1.6, AGC ON) 0 lux with IR on | |
Day/Night | IR‑cut filter with auto switch (ICR) | |
Shutter | Auto/Manual, 1 ~ 1/100000s | |
Adjustment Angle | Pan: 0° ~ 180°, Tilt: 0° ~ 66°, Rotate: 0° ~ 346° | |
S/N | >52 dB | |
WDR | 130 dB | |
Lens | ||
Focal Length | 4.0 mm | |
Iris Type | Fixed | |
Iris | F1.6 | |
Field of View (H) | 81.39° | |
Field of View (V) | 43.36° | |
Field of View (D) | 86.91° | |
Lens Type | Fixed | |
DORI | ||
DORI Distance (Lens) | 4.0mm | |
DORI Distance (Detect) | 90.0m(295.3ft) | |
DORI Distance (Observe) | 36.0m(118.1ft) | |
DORI Distance (Recognize) | 18.0m(59.1ft) | |
DORI Distance (Identify) | 9.0m(29.5ft) | |
Illuminator | ||
Supplemental Light | IR | |
Illumination Distance (IR) | 30 m (98.4 ft) | |
IR On/Off Control | Auto/Manual | |
Wavelength | 850 nm | |
Video | ||
Video Compression | Ultra 265, H.265, H.264, MJPEG | |
H.264 Code Profile | Baseline profile, Main profile, High profile | |
Frame Rate | Main Stream:4MP(2688*1520) ,Max 25fps; 4MP(2560*1440), Max 25fps; 3MP(2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; 720P(1280*720) Max 30fps Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; | |
Video Bit Rate | 128 Kbps to 16 Mbps | |
U‑code | Support | |
OSD | Up to 8 OSDs | |
Privacy Mask | Up to 4 areas | |
ROI | Support | |
Video Stream | Triple Streams | |
Image | ||
White Balance | Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2 | |
Digital Noise Reduction | 2D/3D DNR | |
Smart IR | Support | |
Flip | Normal, Flip Vertical, Flip Horizontal, 180°, 90° Clockwise, 90° Anti‑clockwise | |
Dewarping | N/A | |
HLC | Support | |
BLC | Support | |
Defog | Digital Defog | |
Image Stabilization | N/A | |
Intelligent | ||
Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non‑motor vehicle and vehicle) | |
Statistical Analysis | N/A | |
Events | ||
Basic Detection | Motion Detection, Ultra Motion Detection, Tampering Alarm, Audio Detection | |
General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication, Alarm Input, Alarm Output | |
Audio | ||
Audio Compression | G.711U, G.711A | |
Audio Bitrate | 64 Kbps | |
Two‑way Audio | Support | |
Suppression | Support | |
Sampling Rate | 8 kHz | |
Storage | ||
Edge Storage | Micro SD, up to 512 GB | |
Network Storage | ANR, NAS (NFS) | |
Network | ||
Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS, SSH | |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK | |
User/Host | Up to 32 users. 3 user levels: administrator, common user and operator | |
Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF | |
Client | UNV‑Link, UNV‑Link Pro, EZStation | |
Web Browser | Plug‑in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug‑in free live view: Chrome 57+, Firefox 58+, Edge 16+ | |
Interface | ||
Audio I/O | 1 Input: impedance 35 kΩ, amplitude 2 V [p‑p], 1 Output: impedance 600 Ω, amplitude 2 V [p‑p] | |
Alarm I/O | 1/1 | |
Serial Port | N/A | |
Built‑in Mic | Built‑in two mics | |
Built‑in Speaker | N/A | |
WIFI | N/A | |
Network | 1 × RJ45 10 M/100 M Base‑TX Ethernet | |
Video Output | N/A | |
Certification | ||
EMC | CE‑EMC (EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 50130) FCC (FCC 47 CFR part15 B) | |
Safety | CE‑LVD (EN 62368‑1) UL/CUL (UL 62368‑1, CAN/CSA C22.2 No. 62368‑1) | |
Environment | CE‑RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU) | |
Protection | IP67 (IEC 60529) IK10 (IEC 62262) | |
General | ||
Power | DC 12V±25%, PoE (IEEE 802.3af) | |
Power Consumption | Max 9.1W | |
Power Interface | Ø5.5 mm coaxial power plug | |
Dimensions | 176×104×72mm (6.9” × 4.1’’ ×2.8”) (L x W x H) | |
Weight | 0.62kg(1.37lb) | |
Material | Metal | |
Working Environment | ‑30 ℃ to 60 ℃ (‑22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non‑condensing) | |
Storage Environment | ‑30 ℃ to 60 ℃ (‑22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non‑condensing) | |
Surge Protection | 4 KV | |
Reset Button | Support | |
Web Client Language | 20 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese |
