Easy Series
Products from the Easy series are the most popular choices for entry-level applications such as residential and small retail stores.
Hello, your privacy is important to us. Uniview websites use cookies to store info on your device and create the most secure and effective website . By continuing to use our websites, please accept the cookies could be stored on your device, which outlined our cookie policy and privacy policy .
Products from the Easy series are the most popular choices for entry-level applications such as residential and small retail stores.
Incredibly, you can always find the ideal product in the Prime range, which has even more advanced features to achieve excellent performance.
The Pro series are born with excellent ultra-smart technology, to deliver superior users experience.
High quality image with 4MP, 1/1.8"CMOS sensor
4MP (2688*1520) @ 30/25fps; 4MP (2560*1440) @ 30/25fps; 3MP (2304*1296) @ 30/25fps; 2MP (1920*1080) @30/25fps
Ultra 265, H.265, H.264, MJPEG
Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non‑motor vehicle
Intelligent People Flow Counting and Crowd Density Monitoring
Colorhunter technology ensures 24‑hour full‑color images
120dB true WDR technology enables clear image in strong light scene
Support 9:16 corridor Mode
Alarm:1 in/1 out, Audio: 1 in/1 out
Supports 512 G micro SD card
IK10 vandal resistant
IP67 protection
Support PoE power supply
Model | IPC2324SE‑ADZK‑WL‑AE |
Camera | |
Max Resolution | 4 MP |
Sensor | 1/1.8" CMOS |
Min. Illumination | Colour: 0.0005 lux (F1.2, AGC ON) |
Shutter | Auto/Manual, 1 ~ 1/100000s |
Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360° |
S/N | >56 dB |
WDR | 120 dB |
Lens | |
Focal Length | 2.8 to 12 mm |
Iris Type | Fixed |
Iris | F1.2 |
Field of View (H) | 102.4°~ 49.2° |
Field of View (V) | 54.7°~ 27.8° |
Field of View (D) | 106.8°~55.0° |
DORI | |
DORI Distance (Lens) | 2.8mm, 12mm |
DORI Distance (Detect) | 43.4m(142.4ft), 186.2m(610.9ft) |
DORI Distance (Observe) | 17.4m(57.1ft), 74.5m(244.4ft) |
DORI Distance (Recognize) | 8.7m(28.5ft), 37.2m(122.0ft) |
DORI Distance (Identify) | 4.3m(14.1ft), 18.6m(61.0ft) |
Illuminator | |
Supplemental Light | Dual light |
Illumination Distance (IR) | 30 m (98.4 ft) |
Illumination Distance (Warm Light) | 30 m (98.4 ft) |
Wavelength | 850 nm |
Light On/Off Control | Auto/Manual |
Video | |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
Frame Rate | Main Stream: 4MP (2688*1520), Max 30fps;4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
H.264 Code Profile | Baseline profile, Main profile, High profile |
Video Bit Rate | 128 Kbps to 16 Mbps |
U‑code | Support |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 4 areas |
ROI | Support |
Video Stream | Triple Streams |
Image | |
White Balance | Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2 |
Smart IR | Support |
Digital Noise Reduction | 2D/3D DNR |
Flip | Normal, Flip Vertical, Flip Horizontal, 180°, 90°Clockwise, 90°Anti‑clockwise |
Dewarping | N/A |
HLC | Support |
BLC | Support |
Defog | Digital Defog |
Intelligent | |
Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non‑motor vehicle and vehicle) |
Statistical Analysis | N/A |
People Counting | Support People Flow Counting and Crowd Density Monitoring |
Events | |
Basic Detection | Motion Detection, Ultra Motion Detection, Tampering Alarm, Audio Detection |
General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication, Alarm Input, Alarm Output |
Audio | |
Audio Compression | G.711U, G.711A |
Audio Bitrate | 64 Kbps |
Two‑way Audio | Support |
Suppression | Support |
Sampling Rate | 8 kHz |
Storage | |
Edge Storage | Micro SD, up to 512 GB |
Network Storage | ANR, NAS (NFS) |
Network | |
Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS, SSH |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK |
User/Host | Up to 32 users, 2 user levels: administrator and common user |
Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
Client | UNV‑Link, UNV‑Link Pro, EZStation |
Web Browser | Plug‑in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug‑in free live view: Chrome 57+, Firefox 58+, Edge 16+ |
Interface | |
Audio I/O | 1 Input: impedance 35 kΩ, amplitude 2 V [p‑p], 1 Output: impedance 600 Ω, amplitude 2 V [p‑p] |
Alarm I/O | 1/1 |
Serial Port | N/A |
Built‑in Mic | Built‑in two mics |
Built‑in Speaker | N/A |
WIFI | N/A |
Network | 1 × RJ45 10 M/100 M Base‑TX Ethernet |
Video Output | N/A |
Certification | |
EMC | CE‑EMC (EN 55032: 2015+A1:2020,EN 61000‑3‑3: 2013+A1: 2019,EN IEC 61000‑3‑2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4‑2014) |
Safety | CE LVD (EN 62368‑1:2014+A11:2017) CB (IEC 62368‑1:2014) UL (UL 62368‑1, 2nd Ed., Issue Date: 2014‑12‑01) |
Environment | CE‑RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Protection | IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) |
General | |
Power | DC 12V±25%, PoE (IEEE 802.3af) |
Power Consumption | Max 11.5W |
Power Interface | Ø5.5 mm coaxial power plug |
Dimensions | 245× 86 × 85mm (9.6” × 3.4” × 3.3”) (L x W x H) |
Weight | 0.9kg (1.98lb) |
Material | Metal |
Working Environment | ‑30 ℃ to 60 ℃ (‑22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non‑condensing) |
Storage Environment | ‑30 ℃ to 60 ℃ (‑22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non‑condensing) |
Surge Protection | 6 KV |
Reset Button | Support |
Web Client Language | 20 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese |
