Model | MW3586-T-Y1 | ||
Display | |||
Screen Size | 86 inches | ||
Backlight | DLED | ||
Pixel Pitch(mm) | 0.493 x 0.493mm | ||
Resolution | 3840*2160 | ||
Brightnes(cd/m2) | 350 | ||
Contrast | 1200:1 | ||
Response Time(ms) | 8 | ||
Color | 1.07B | ||
Viewing Angle | Horizontal 178°, Vertical 178° | ||
View Area(W*H) | 1895.04mm(L)*1065.96mm(H) | ||
Android System | |||
RAM | 8G | ||
ROM | 128G | ||
CPU | A73*4(2.28GHZ)+ A53*4(2.0GHZ) | ||
OS | Android 13.0 | ||
Touch | |||
Sensing Type | Infrared Touch Frame, support 20 touch points | ||
Glass | 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare | ||
Touch Accuracy (mm) | ±2 | ||
Response Time (ms) | ≤8 | ||
Recognizable object (mm) | 2 | ||
Touchscreen input | Opaque objects (e.g. finger, pen, etc.) | ||
Support System | Windows10/Windows8/Windows7/Windows XP/Android/Linux/Mac OS X/Chrome | ||
Interface | |||
Video Input | 3 x HDMI IN 1 x DP IN 1 x VGA IN | ||
Video Output | 1 x HDMI OUT | ||
Audio Input | 1 x MIC IN, 3.5mm interface 1 x VGA AUDIO IN | ||
Audio Output | 1 x Line OUT, 3.5mm interface 1 x COAX OUT | ||
Other Interfaces | 5 x USB3.0、2 x USB 2.0、2 x Type C、3 x Touch USB、1 x RS232、1 x USB 2.0 OTG、1 x TF | ||
Network | 2 x RJ45, supports 10M/100M Base‑T self‑adaptive | ||
Camera & Microphone | |||
Pixel | 48MP Android: Pixel 13MP for Photos & 8MP for Video Windows: Pixel 48MP for Photos & 48MP for Video | ||
viewing angle | D=118.3°, H=99.2°, V=69.7° | ||
Microphone array | 8 | ||
Pickup distance | 8 | ||
Smart function | Auto Framing;Speaker Tracking; | ||
Speaker | |||
Speaker | 2*20W+20W | ||
Channel | 2.1 | ||
NFC | |||
NFC | Support screen mirroring by Android phones | ||
Bluetooth | |||
Version | 5.0 | ||
Dual-module WIFI6 | |||
Version | Wifi :802.11 b/g/n AP :802.11 a/b/g/n/ac | ||
Working Frequency | 2.4GHz/5GHz | ||
Working Distance(m) | 0~12 | ||
General | |||
Power Supply | AC90V to AC264V | ||
Overall power consumption (W) | ≤285 (without OPS) | ||
Consumption(W) | ≤0.5(Standby) | ||
Operation Temperature | 0°C~40 °C | ||
Operating Humidity | 10%~80% (No Condensation) | ||
Storage Temperature | -20~60℃ | ||
Storage Humidity | 10%~90%(No-condensing) | ||
Product Size(W*H*D) (mm) | 1953.2*1166*115.8 | ||
Packing Size(W*H*D)(mm) | 2086*1291*220 | ||
Weight(kg) | Net Weight:58 Gross Weight:79 | ||
Accessory | |||
Standard | 2*Touch Pen、1*Wall Mount、1*power cord、1*quick guide、1*Remote control、 |
