MW-LC22-IPS2 - Uniview - Leader of AIoT Solution

MW-LC22-IPS2

22＂LED monitor

Resolution is up to at 1920*1080.

Refresh rate up to 100Hz.

178°horizontal and vertical viewing angle.

Screen can reduce blue light, protect eyes.

Stable structure design, highly durable.

Specification

Download

Want to learn more?

Panel	Description
Panel Type	LED Backlight
Panel Size	22
Resolution	1920*1080
Color Support	16.7M
Brightness (cd/m²)	250
Contrast Ratio	1000:1
Refresh Rate	100Hz
Response Time (ms)	5ms(OD ON)
Viewing Angle (H/V)	Horizontal 178°, Vertical 178°
Operation time	7 * 24 h
Lifespan	30000 h
Interface	Description
Video Input	1* HDMI、1*VGA
VESA	Description
VESA（mm）	75*75
General	Description
Input Voltage	DC 12V, 2A
Typical power consumption （W）	≤22 (on)
Standby power consumption （W）	≤0.5(Standby)
Product Dimensions （WHD）（mm）	492.7284.041.2
Package Dimensions （WHD）（mm）	59899366
Weight（Kg）	Net Weight:2.18 Gross Weight:3.12
Operation Temperature	0°C ~ 40 °C
Operating Humidity	10%~85% (No Condensation)
Storage Temperature	-10°C ~ 50°C
Storage Humidity	10%~90% (No Condensation)
Standard	1* Monitor base、1HDMI cable、1 Power adapter、1*Quick Guide (Adjust according to customer needs)
