| DEU1016-B | ||||||||
| Hard Disk | ||||||||
| SATA | 16 SATA Interfaces | |||||||
| Capacity | Up to 16TB for each disk | |||||||
| External Interface | ||||||||
| miniSAS | 1 | |||||||
| RS232 | 1 | |||||||
| Power Supply | AC 100~240V | |||||||
| Working Environment | ||||||||
| Working Temperature | -10 ℃ ~ + 55 ℃ (+14 ℉ ~ +131 ℉) | |||||||
| Working Humidity | 5%~95% RH (non-condensing) | |||||||
| Power Consumption (With HDD) | < 160W(With 16 HDDs) | |||||||
| Dimensions | ||||||||
| Weight (Without HDD) | < 10Kg (22lb) | |||||||
| Dimensions | 482mm × 477mm× 131mm (19.0"×18.8"×5.1") | |||||||
| Height | 3U | |||||||
| Class | Date | Title | Language | Type | Preview | Download |
| Datasheet | 2025/8/26 19:31:27 | UNV DEU1016-B Disk Enclosure.pdf | English | Preview | Download A > |
| Class | Date | Title | Type | Download |
| HD Image | 2025/10/28 3:09:18 | DEU1016-B_HD_Image_1.png | png | Download |
| HD Image | 2025/10/28 3:09:18 | DEU1016-B_HD_Image_2.png | png | Download |
| HD Image | 2025/10/28 3:09:18 | DEU1016-B_HD_Image_3.png | png | Download |
| Class | Date | Title | Language | Type | Preview | Download |
| Quick Guide | 2025/6/7 4:02:53 | Quick Guide.pdf | English | Preview | Download A > |
| Class | Date | Title | Download |
| Dimensions | 2025/10/28 3:09:18 | DEU1016-B_Dimensions_1.png | Download |
