IPS302030-S | ||||||||
Speaker | ||||||||
Rated Power | 30 W | |||||||
Max. Acoustic Pressure | 130 dBSPL | |||||||
Frequency Response | 300 Hz to 12.5 kHz | |||||||
Impedance | 8 Ω | |||||||
Material | ||||||||
Material | ABS Plastic | |||||||
Network | ||||||||
Network Protocol | IPv4, HTTP, HTTPS, SSL/TLS, DNS, TCP, UDP, DHCP, UPnP, ARP, SSH | |||||||
Interface Protocol (API) | ONVIF, RTSP, RTP, LAPI | |||||||
Browser | Firefox 87+, Chrome 90+, Edge 90+, Safari 17+ | |||||||
Build in Mic | ||||||||
Amount | 1 | |||||||
Frequency Response | 100 Hz to 8 kHz | |||||||
Sensitivity | -37 dBV/Pa | |||||||
Sampling Rate | 8 kHz | |||||||
Quantization Bits | 16 bit | |||||||
Audio | ||||||||
Broadcast | Regular Broadcast, Live Broadcast, Alarm Broadcast | |||||||
Two-Way Audio | Support | |||||||
Audio Compression | G.711U | |||||||
Audio File Format | MP3, WAV | |||||||
Audio File Size | 2 KB ≤ Audio File Size ≤ 10 MB | |||||||
Audio File Storage | 64 MB | |||||||
Audio File Number | 100 (Include system built-in files ) | |||||||
Language | ||||||||
Language | 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian | |||||||
Interface | ||||||||
Network Interface | 1 RJ45 10 M/100 M self adaptive Ethernet Interface | |||||||
Audio In | 1, RCA | |||||||
Alarm In | 2 | |||||||
Power Supply | PoE (IEEE 802.3at), DC 24 V/1.4 A, DC 12 V/2.5 A | |||||||
Working Environment | ||||||||
Working Temperature | -30 ℃ to 55 ℃ (-22 ℉ to 131 ℉) | |||||||
Working Humidity | ≤ 90% RH (non-condensing) | |||||||
Dimensions | ||||||||
Dimensions | 282mm × 205mm× 285mm (11.1"×8.1"×11.2") | |||||||
Approval | ||||||||
Protection | IP66 |
