NSW1010-8T-IN | ||||||||
Hardware Specification | ||||||||
Ports Type | 8 x 10/100Mbps port (RJ45) | |||||||
Network Media | 10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m) 100Base-TX: Cat5 or higher UTP/STP (≤100m) | |||||||
Switching capacity | 1.6Gbps | |||||||
Forwarding performance | 1.19Mpps | |||||||
MAC | 2K | |||||||
Jumbo Frame | 15K | |||||||
Transfer Mode | Store-and-forward | |||||||
Dimensions (W×D×H) | Product: 145*60*21.5mm Packaging: 146*88*50mm | |||||||
Carton Information | Carton dimensions: 530*475*315mm Carton quantity: 100PCS Carton weight: 17.6kg | |||||||
Weight | Product: 0.111kg Packaging: 0.166kg | |||||||
Power Supply | Adapter input voltage: AC 100V to 240V Switch input voltage: 5V, 1A | |||||||
Mount Method | Desktop mount, wall mount | |||||||
Cooling Fans | 0 | |||||||
Operating temperature | 0 °C ~ 40 °C (32 °F ~ 104 °F) | |||||||
Operating humidity | 10%~90% (noncondensing) | |||||||
Storage Temperature | -20°C to 70°C | |||||||
Storage Humidity | 5% to 90% RH, noncondensing | |||||||
Indicator | POWER Steady on: AC input is normal, POWER Off: No AC input, LINK/ACT Off: No link, LINK/ACT Flashing: Transmitting data, LINK/ACT Steady on: Linked |
